220V /110V Fast Charging Within 2.5 Hours MPPR Support Portable Power Station With APP/Bluetooth For Outdoor Blackout
Quick Details :
- Multiple output port protocols:PD3.0,Apple2.4A,DCP-1.5A,SAMSUNG-AFC,HW -FCP,QC2.0,QC3.0,HW-SCP.
- ABS plastic shell, heat-resistant and non-deformable, with high impact resistance under low and Higher temperature conditions
- Advanced BMS Protection: built-in battery management system regulates vitals, including voltage, current, and temperature, keeping 1200WF1 safe, secure, and built to stand the test of time.
-
A clean energy alternative.Replace noisy, smoky generators with a silent, fume-free, portable home battery. Unlike generators, batteries are ideal for both outdoor and indoor use, running all your essentials during a blackout. And, with the help of solar energy, recharge during an extended outage.
- We are support Battery Pack Color /Battery Cell Customized etc
- Built-in intelligent BMS.
Application: Lightening System,Home Backup System,EV Power Supply,Residential Backup Power System,Outdoor Camping,Hiking,UPS Power Supply /Office Equipment/Mobile Phone Power Supply/Outdoor Blackout /Power Tools/Home Appliance/Disaster etc
| 1200W Two-way Inverter Portable Power Station Specification |
| Battery | Battery Cell Type | Lithium Iron Phosphate Battery |
| Battery Cell Combination Method | 7S3P/7S2P |
| Each Battery Cell Capacity | 15AH/24AH |
| Each Battery Cell Voltage | 22.4V |
| Battery Pack Capacity | 1008WH/1075WH/Customized |
| BMS | Over-charge protection, Over-Discharge protection, Over-current protection, Short Circuit protection, High Temperature protection, Balance Charge/Discharge protection, |
| Input | XT60 Input Voltage | Standard:18V Minmum Voltage~Maximum Voltage :5.7V~36V |
| XT60 Input Current | Standard:10A Minmum Voltage~Maximum Voltage :7.5A~16A |
| XT60 Charge cut-off current | Standard:3A Minmum Voltage~Maximum Voltage :2A~5A |
| XT 60:Car Charging | 12V charging current is 10A |
| MPPT Solar Charging | Supports up to 400W solar charging |
| AC Input Voltage | 220V/Customized 110V |
| AC Frenquency One-click conversion | 50HZ/ 60HZ |
| Input surge current | 20A |
| Output | USB-A Port | 5V/3.37A; 9V/2A;12V/1.5A MAX18W |
| USB-B Port | 5V/3.37A; 9V/2A;12V/1.5A MAX18W |
| USB-C Port | 5V/3.37A; 9V/2A;12V/1.5A MAX18W |
| Type-A/B/C port protocol | PD3.0,Apple2.4A,DCP-1.5A,SAMSUNG-AFC,HW -FCP,QC2.0,QC3.0,HW-SCP. |
| Type-A Port | PD MAX 64W5V*3A/9V*3A/12V*3A/15V*3A/20V*3.2A |
| Type-B Port | PD MAX 64W 5V*3A/9V*3A/12V*3A/15V*3A/20V*3.2A |
| Type-C Port | PD MAX 64W 5V*3A/9V*3A/12V*3A/15V*3A/20V*3.2A |
| AC Output Voltage | 220V/Customized 110V |
| AC Output Frequency | 50HZ/Customized 60HZ |
| AC Outlet | 4 Units |
| AC output waveform | Pure Sine Wave |
| AC Output Power | 1200W |
| AC instantaneous output power | ≤1300W |
| AC charging and discharging at the same time | Support ,Charging power is about 260W |
| DC Cigerette Output Voltage and Current | 13V/7.8A Max Power 105W |
| Physical Charateristic | LCD Display Screens | Yes .Power 2W |
| LED Light | Working on,SOS |
| Dimension | L345*W220*H190mm |
| Net Weight | 13.2Kg |
| Working Environment | Discharge | -10℃～45℃ |
| Charge | 0℃～65℃ |
Product design needs to meet the safety certification requirements of different countries.
Our company can provide product certifications as follows: FCC, UN38.3, UL2743, PSE, MSDS, ETL;
1.EN55022 electromagnetic compatibility related
2.IEC60950-1:2005+A1:2009+A2:2013 safety regulations
3.UN38.3 Transportation safety requirements for lithium battery products
4.SP188 Maritime safety requirements for lithium battery products
5.IEC62133 Lithium battery product safety requirements
6.UL1642 lithium battery pack safety requirements
7.UL2743 Portable power pack safety requirements
8.PSE Japan Electrical Product Safety Law
9.GB31241 Safety requirements for lithium-ion batteries and battery packs for portable electronic products
10.GB-T 20321.2-2006 Off-grid inverter test standard
Comply with environmental protection laws and regulations: ROHS regulations.
FAQ:
Q:Do you have different specifications of folding panels? For example, 200W.400W.800W.100W or more
A:Yes, our solar panel material is Jinko raw material, and the conversion efficiency is about 23%
Q:How many appearance styles do your folding solar panels have?
A:We have more than 10 styles of folding bags. If you want specific information, please contact our sales team
Q:How long can your charging station provide power if the power is cut off at any time?
A:Our charging station can provide power within 10 to 20 seconds
Q:How many years of warranty do you have?
A:3~5 Years .We can prolong the warranty
Q:Can you customize the AC outlet specifications?
A:Yes, please let our sales team know when placing an order.Thank you
Q: Can you OEM/DOM?
A:Yes
